Victron VE. Direct Cable Straight - Straight 3 m (ASS030530230)

The Victron ASS030530230 is a 10-meter VE.Direct cable designed for high-speed data communication between Victron Energy components. This specialized 33-foot cable serves as the essential physical link for integrating power electronics into a centralized monitoring network, such as the Cerbo GX or Color Control GX.

Purpose and Connectivity

The VE.Direct interface is a proprietary protocol used to transmit real-time data from individual components to a system controller. This cable is commonly used to connect the following devices to a GX-series communication hub:

• BlueSolar and SmartSolar MPPT Charge Controllers.

• BMV-700 and BMV-712 Battery Monitors.

• Phoenix Inverters equipped with a VE.Direct port.

• Blue Power and Blue Smart IP22/IP65 Chargers.

Data Transmission Capabilities

By linking a component to a GX device via this cable, users gain access to advanced system diagnostics. The cable carries critical live data, including battery voltage, current flow, solar harvest statistics, and load status. This information is then processed for display on a local touchscreen or for remote monitoring via the Victron Remote Management portal.

Technical Specifications and Design

• Length: 10 meters (33 feet), providing sufficient reach for routing through large vessels, RVs, or off-grid solar enclosures where the monitor and power hardware are in separate locations.

• Connectors: Features molded 4-pin VE.Direct connectors on both ends, designed for a secure friction-fit that resists the vibrations common in marine and automotive environments.

• Build Quality: The cable is shielded to prevent electromagnetic interference from surrounding high-voltage wiring, ensuring a stable and accurate data signal.

• Profile: The thin, flexible jacket allows for easy installation through narrow conduits and behind cabinetry without adding bulk to wire looms.

Installation Note

This is a dedicated data cable for device-to-device or device-to-GX communication. It is not compatible with standard USB ports; for connecting a VE.Direct device directly to a computer or certain mobile devices, a separate VE.Direct to USB interface cable is required.
