Sheave Ø (mm) | 57 mm |
Sheave Ø (in) | 2 1/4 in |
Length (mm) | 121 mm |
Length (in) | 4 3/4 in |
Weight (g) | 255 g |
Weight (oz) | 9 oz |
Shackle pin Ø (mm) | 6 mm |
Shackle pin Ø (in) | 1/4 in |
Maximum line Ø (mm) | 10 mm |
Maximum line Ø (in) | 3/8 in |
Maximum working load (kg) | 1080 kg |
Maximum working load (lb) | 2380 lb |
Breaking load (kg) | 2270 kg |
Breaking load (lb) | 5000 lb |
