Ypower 12V / 16 Amp Charger 3 bank

• New generation
• Automatic and Autonomous
• Plug & play : easy connection
• Silent
• High temperature performance
• CAN-BUS interface
• Remote touch-screen control panel

Plug & Play connectors

• Quick, reliable and friendly mounting. Charger to be located in tighter places.
• AC & DC plug connectors included.

Silent operating

• Fanless Operation

High temperature performance

• Rated charge up to +60°C with no derating
• Can be installed in an engine room

Worldwide use

• 90-265VAC/47-65Hz auto-ranging
• Design and construction according to UL-1236 marine and CSa 22.2-107.2 standards
• Meet also ABYC A-31 requirements

5-stage charging profile

1. Boost : charges batteries to 80% of full charge
2. Absorption : slowly completes remaining charge to 100%
3. Floating : maintains battery charge
4. Automatic refresh : PREVENTS SULPHATION AND REVITALIZES BATTERIES, SELECTABLE BY INTERNAL SWITCH
5. Reboost : new automatic Boost phase if batteries demand needs it Power-supply mode also available IU mode by BOOST inhibiting by internal switch

3 isolated battery banks

• Automatically senses and distributes 100% of available charging Amps to any one bank or combination of all banks
• One bank dedicated to the engine battery + BAT E
• Integrated electronic MOSFET charge separator Protection of the charger during engine starting phase
