Dimensions: Diameter | Height |
541.0 mm | 209.5 mm |
Weight |
5.6 kg |
Supply voltage |
Either 12 V dc or 24 V dc nominal |
Operating voltage range |
Minimum: 10.8 V dc | Maximum: 31.2 V dc |
Power Consumption |
Transmit mode (maximum): 17 W | Standby mode: 7 W | Sleep mode (applies only to radars connected via Wi-Fi): 2 W |
Waterproofing |
IPX6 |
Operating temperature range |
-10°C to +55°C |
Storage temperature range |
-25°C to +70°C |
Additional storage conditions |
Store upright; do not block vents on underside |
Humidity |
Up to 95% at 35°C |
Maximum wind speed |
100 kts |
Range scales |
1/16, 1/8, 1/4, 3/8, 1/2, 3/4, 1, 1.5, 2, 3, 4, 6, 8, 12, 16, and 24 nautical miles |
