Specifications | |
---|---|
Action | OFF-ON |
Amperage | 10A @ 12V DC Resistive 3A @ 12V Inductive |
Nominal Voltage | 12V DC |
Maximum LED Operating Current | 20mA |
Minimum Operating Temperature | -30° C |
Maximum Operating Temperature | 70° C |
Minimum Storage Temperature | -55° C |
Maximum Storage Temperature | 85° C |
Illumination | Independent – Separate contacts for LED power |
Max Panel Thickness | 0.31in (7.87 mm) |
Mounting Hole | ¾” (19mm) |
Switching Cycles | 40,000 |
Termination | 5 – 0.110inch Quick Connect terminals |
Weight | 0.20lb (0.09 kg) |
