Prosafe -30A Failsafe Galvanic Isolator

The ProSafe Fail-Safe 30 Galvanic Isolator will interrupt galvanic current flow with other boats at a marina when installed on a boat which is connected to AC Shore Power.

This technology maintains AC safety ground and solves the most common forms of corrosion and premature zinc loss within a boats bonding system.

The ProSafe FS Series is UL Certified to meet the parameters of the ABYC A-28 recommendation.

ProSafe FS installs easily and does not require a dedicated monitor to verify the operational status of the galvanic isolator as required by non FailSafe Certified galvanic isolators.

Both the ProSafe 30 and 60 Amp models are built on robust Flat Pack Semiconductor platforms, ensuring that in the event of a failure, the failure is safe by not compromising the ground continuity on-board when connected to AC Shore Power.

• ABYC A-28 July '08; Compliant and Fail Safe Certified
• Certified by Underwriters Laboratories (UL). Insures shore power safety ground wire is maintained through the isolator.
• Robust high power diodes allow the FS Series to meet the criteria for conducting inrush currents of 3,000 amps for the required duration period.
• Ignition Protected
• Meets ISO 8846 and can be mounted within an engine compartment.
• Gold Plated Terminations

• Shore cord inlet compatibility: Single 15, 16, 20 or 30A
• Ratings VAC / Max AMPS /Hz: 120/240 VAC/41A /50 or 60 HZ
• Max temp.: 50° C
• Size L x W x H: 6.75" x 7" x 2.5"
• Weight: 3 lbs
