Length (mm) | 231 mm |
Length (in) | 9 1/8 in |
Width (mm) | 111 mm |
Width (in) | 4 3/8 in |
Height (mm) | 89 mm |
Height (in) | 3 1/2 in |
Weight (g) | 1736 g |
Weight (oz) | 61 oz |
Maximum working load (kg) | 2268 kg |
Maximum working load (lb) | 5000 lb |
Breaking load (lb) | 10000 lb |
Breaking load (kg) | 4536 kg |
Minimum curved track radius (m) | 7.32 m |
Minimum curved track radius (ft) | 24 ft |
Mainsheet block pin Ø (mm) | 8, 10 |
Mainsheet block pin Ø (in) | 5/16, 3/8 in |
Use with track/rail | R32HB |
Part No. T3244B
Maximum working load (kg) 2268 kg
Maximum working load (lb) 5000 lb
Length (mm) 231 mm
Length (in) 9 1/8 in
