Amperage | 80A AC 80A DC |
Color | White |
Actuator Style ![]() |
Toggle |
Poles | 1 |
Maximum Voltage | 240V AC 65V DC |
Circuit Breaker Type | Magnetic Hydraulic - trip free |
Terminal Stud | 1/4-20 Tin-Plated Brass |
Terminal Stud Torque | 35 in-lb (3.95 Nm) |
Interrupt Capacity ![]() |
5000A @ 125V AC 5000A @ 240V AC 10000A @ 80V DC |
Minimum Operating Temperature | -40° C |
Maximum Operating Temperature | 85° C |
Mounting Screw | #6-32 Stainless Steel |
Mounting Screw Torque | 6 in-lb (0.68 Nm) |
Switching Cycles | 10000 |
Weight | 0.36lb (0.16 kg) |
