Sheave Ø (mm) | 75 mm |
Sheave Ø (in) | 2 15/16 in |
Length (mm) | 137 mm |
Length (in) | 5 3/8 in |
Weight (g) | 195 g |
Weight (oz) | 6.9 oz |
Maximum line Ø (mm) | 14 mm |
Maximum line Ø (in) | 9/16 in |
Maximum working load (kg) | 550 kg |
Maximum working load (lb) | 1213 lb |
Breaking load (lb) | 3638 lb |
Breaking load (kg) | 1650 kg |
Shackle pin Ø (mm) | 6 mm |
Shackle pin Ø (in) | 1/4 in |
